Colour Japtile
Colour Japtile

Colour Japtile

Traditional beauty of clay roofing tiles with less intense maintenance, easier installation and high cost-saving while providing better durability and strength effectiveness.

Features

  • Cost saving alternative to conventional ceramic tiles profile

  • Lighter weight resulting in further cost savings for structure support

  • Standard module length : 300 mm
    (Special customized order can be made from 200 mm to 400 mm)

  • Effective coverage : 760 m

  • Rib Height from base of pan : 33.5 mm

  • Step Height : 10mm

Thickness Available
  • 0.40 mm
  • 0.47 mm


Technical Data

Dimensions

Total Coated Thickness (mm) 0.40 0.47
Width Coverage (mm) 760 760
Minimum Recommend Pitch (Degree) 15° 15°

Span Distance Roof (mm)

Single 1100 1100
End 1000 1000
Internal 1500 1700

Span Distance Wall (mm)

Single 1500 1800
End 1500 1800
Internal 1800 2200

Recommended Roofing Pitch

  • The minimum recommended roof pitch is 15° or more.

  • Roof pitch lesser than 15° will collect dust which eventually may cause corrosion due to long term moisture retention.

Material Specifications

Materials used for LSL Colour LOK meet stringent tests as tensile strenght. QUV simulate, cyclic corrosion,
QCT, gloss uniformly, T-bend, impact resistance and optical admission.

Base Metal Steel Complies With JIS G3312; AS1397; MS1196
Minimum Tensile Strength 350 to 550 MPa
Base Steel Coating Zinc Coated (Z18) or Aluminum Zinc 55% Coated (AZ150)
Primer Coat Epoxy Finish (Top Coat)

Utilizing State-of-the-Art INFRA-RED Coating Technology, Our Paint System provides Ultimate Weathering Resistance
with outstanding Colour Retention Durability:


PREMIUM Series

Paint System Polyester Coated Paint System
Warranty 5 Years Colour Warranty
10 Years Corrosion Warranty
Features Energy-Efficient, Solar Reflectice, Finish meeting, Energy Star standards and requirements.
Environmental Friendly with Mercury and Lead-Free coatings

ELITE Series

Paint System 100% High End Ceramic Polyester Paint
Warranty Warranty 10 Years Colour Warranty
25 Years Corrosion Warranty
Features Energy-Efficient, Solar Reflectice, Finish meeting, Energy Star standards and requirements.
Environmental Friendly with Mercury and Lead-Free coatings

PVDF Series

Paint System Poly Vinyl Fluoride (PVF2), Genuine 700% Full Strength Kynar 500® or Hylar 500® Flourocarbon Paint System
Warranty 20 Years Colour Warranty
25 Years Corrosion Warranty
Features Energy-Efficient, Solar Reflectice, Finish meeting, Energy Star standards and requirements.
Environmental Friendly with Mercury and Lead-Free coatings

Coating Specifications

Coating Specifications
Solar Reflectivity (SR)

Solar reflectivity or reflectance is the ability of a material to reflect solar energy from its surface back into the atmosphere. The SR is value is a number from 0 to 1.0 A Value of 0 indicates that the materials absorbs al solar energy and a value of 1.0 indicates total reflectance. Energy Star requires and initial SR value of 0.25 or higher for steep slope (>2:12) roofs and 0.15 or greater after three years. Low slope roofs require an initial SR value of 0.65 or higher and 0.50 or greater after three year.


Solar Reflectance Index (SRI)

The Solar Reflectance Index is used for compliance with LEED requirements and is calculated according to ASTM E 1980 using values for reflectance and emissivity. Emissivity is a material’s ability to release absorbed energy. To meet LEED requirements a roofing material must have a SRI of 29 or higher for steep slope (>2:12) roofing and a SRI value of 78 or higher for low slope roofing.

  Top Back
  Primer Backer Primer Backer
PREMIUM Series 5 15-18 5 5
ELITE Series 5 18-20 5 5
PVDF Series 5 18-20 5 5
